Tool Preset CNC Display
Preset the tool carousel with the M94 & M97 commands.
Go to MDI and type in M97T???; Insert into MDI program block and press cycle start (??? = what tool is in spindle; i.e. M97T103. If there is no tool in the spindle then type code = M97T100).
Now type in M94T???; Insert into MDI program block & press CYCLE START (??? = what tool is facing spindle, i.e. M94T103)
